Raven RP89 Door Bottom Sweep Seal 9mm – 1000mm – Black
Original price was: $38.46.$26.92Current price is: $26.92.
- Safe Shopping Guaranteed
- Safe Payments, Happy Customers
- No-Questions-Asked Returns
- The quality solution for all your needs.
A rigid and flexible co-polymer weather and energy seal. RP89 suits leading proprietary brand, hollow channel aluminium door suites. Concealed in the bottom of aluminium butt hinged doors or the bottom and head of pivot doors, RP89’s unique design accommodates OEM and retrofit applications.
When used in conjunction with a Raven threshold plate an excellent weather and energy seal is achieved.
Location: Bottom or top of 40-45mm hollow channel aluminium doors. Suits butt hinged and pivot hinged systems. Sliding doors (user determined).
Min/Max Gap: 6mm to 9mm.
Note: A Raven threshold plate is recommended to clear floor surface.
Fixing: Snap fit design with end support lugs and screws supplied.
Seal: Black rigid and grey flexible UV stabilised co-polymer.
Sizes: 1000mm.
Approvals
Energy NCC Pt. 3.12.3.3 & J3.4.
Durability Tested to over 500,000 operating cycles without failure.
Registered Design.
| MPN | A891000 |
|---|---|
| Suitable for Door Type | Aluminium Doors |
| Self Adhesive | No |
| Max Door Gap | 9mm |
| Min Door Gap | 6mm |
| Gasket Material | Co-Polymer |
| Brush / Gasket Length | 9mm |
| Seal Can Be Installed | Rebated |
| Contains Intumescent Material | No |
| Bush Fire Attack Level | BAL <29 |
| Suitable for Smoke Doors | Yes |
| Brand | Raven |
| Acoustic Rated to AS1191 and ISO140.3 | Yes |
| Fire Tested | No |
| Includes Fixing Screws | No |
| Product Material | Co-Polymer |
| Product Finish or Colour | Black (BLK) |
| Product Thickness | 44mm |
| Door Seal Length | 1000mm |
| Product Length | 1000mm |
| Product Height | 18mm |
| Product Warranty | 2 Years |
