Raven RP18 Threshold Plate 25mm – Clear Anodised Aluminium
Original price was: $129.78.$90.85Current price is: $90.85.
- Safe Shopping Guaranteed
- Safe Payments, Happy Customers
- No-Questions-Asked Returns
- The quality solution for all your needs.
A heavy duty threshold plate designed for butt hinged, single, double, or pivot hinge doors. It allows the door leaf to clear high pile carpets which have been laid up to the frame. It has been designed to accommodate concealed screw fixings through the door jambs.
An aluminium door frame, complete with the threshold plate, can be assembled by a door fabricator prior to transporting as a complete unit. RP18 will accommodate Pivot Sets for most types of Transom Closers.
Used in Conjunction with Raven door bottom seals RP2b and RP74 (RP8Si butt hinged doors).
Location: Door sill of single, double butt hinged or pivot hinged doors.
Finish: Satin clear (silver) or bronze anodised aluminium (25micron).
Fixing: By door fabricator.
Sizes: Available in stock lengths.
Approvals
UL Cert. GVYI.R37913
| Product Length | 1000mm, 2000mm, 3000mm |
|---|---|
| MPN | A18C |
| Brand | Raven |
| Product Width | 100mm |
| Product Height | 25mm |
| Product Finish or Colour | Clear Anodised (CA) |
| Product Material | Aluminium |
| Includes Fixing Screws | Yes |
| AS1428.1 Compliant | No |
| Fire Tested | No |
| Acoustic Rated to AS1191 and ISO140.3 | No |
| Product Warranty | 2 Years |
