Raven RP138 Threshold Plate 13mm – Clear Anodised Aluminium
Original price was: $99.41.$69.59Current price is: $69.59.
- Safe Shopping Guaranteed
- Safe Payments, Happy Customers
- No-Questions-Asked Returns
- The quality solution for all your needs.
A heavy duty threshold ramp that can be used as a border for internal floor matting or be positioned back to back to form a two way threshold ramp conforming to NCC Pt. D2.15 Thresholds (b).
Ideal for larger style commercial door frames.
RP138 has been designed to accommodate a concealed screw fix through the door jambs.
Location: Door sill.
Finish: Satin clear (silver) anodised aluminium (25micron).
Fixing: Screw fix or builders adhesive for concealed fixing (user determined). Colour matched zinc plated, cross recess head CSK S.T. screws supplied.
Sizes: 3000mm, 2500mm, 2000mm, 1250mm, 1000mm.
Approvals
UL Cert. GVYI.R37913
Access & Mobility AUS/NZ: NCC D2.15 & D3.3. AS1428.1. NZ BC Compliance Doc. D1/AS1 1.3.2.
UK/EU: Approved Document M.
Fire AUS/NZ: NCC Spec. C3.4. AS1530.4 & AS/NZS 1905.1. NZ BC Compliance Doc. C/AS1 6.19.2(a) & App. C6.1.1.
UK/EU: Approved Document B. BS 476 Pt. 20 & 22 (similar to BS EN 1634-1).
FRL & FRR-/240/30 and FD180. Fire Approved
Fire Approved when used with a BAL rated door bottom seal in accordance with AS 3959.
| Product Length | 1000mm, 1250mm, 2000mm, 2500mm, 3000mm |
|---|---|
| MPN | A138C |
| Brand | Raven |
| Product Width | 150mm |
| Product Height | 13mm |
| Product Finish or Colour | Clear Anodised (CA) |
| Product Material | Aluminium |
| Includes Fixing Screws | Yes |
| AS1428.1 Compliant | Yes |
| Fire Tested | Yes |
| Acoustic Rated to AS1191 and ISO140.3 | No |
| Product Warranty | 2 Years |
