Kilargo IS7061 Meeting Style – Astragal Seal – Clear Anodised Aluminium
Original price was: $77.62.$54.33Current price is: $54.33.
- Safe Shopping Guaranteed
- Safe Payments, Happy Customers
- No-Questions-Asked Returns
- The quality solution for all your needs.
An astragal seal used with either plain or rebated meeting stiles on single swing, double doors (where only one door leaf is active). It provides an excellent acoustic, smoke, light, dust and weather seal. This seal combines with proven smoke and acoustic performance, sealing on two faces of the door surface. The thin fixing leg allows this seal to be face fixed to the door (no rebating required). This leg can also be checked to make way for locks and latches.
Gap Size
- Min. 2.5mm / Max. 6mm
Standard Lengths
- 2250mm
- 2500mm
- 3000mm
- Also available in: 250mm increments from 2000mm to 3500mm (Special Order Only)
Standard Finishes
- Silver anodised aluminium with black sealing blades
Fixing
- Â A door sequence selector should be considered unless one leaf is intended to be fixed
Approvals
- Medium temperature smoke leakage approvals to AS1530 Part 7 available on proprietary door assemblies
- Conforms with NCC Specification C3.4 smoke sealing requirements
- Acoustically tested in accordance with AS1191, IS0140.3 and ISO10140-2
- Durability tests demonstrating over 100,000 open & close cycles
| Door Seal Length | 2250mm, 2500mm, 3000mm |
|---|---|
| Suitable for Door Type | Timber Doors |
| Self Adhesive | No |
| Max Door Gap | 6mm |
| Min Door Gap | 2.5mm |
| Gasket Material | Silicon |
| Gasket / Seal Colour | Black |
| Seal Can Be Installed | Surface Fix |
| Contains Intumescent Material | No |
| Suitable for Smoke Doors | Yes |
| MPN | IS7061 |
| Acoustic Rated to AS1191 and ISO140.3 | Yes |
| Fire Tested | No |
| Includes Fixing Screws | Yes |
| Product Material | Aluminium |
| Product Finish or Colour | Clear Anodised (CA) |
| Product Thickness | 18mm |
| Product Width | 25mm |
| Brand | Kilargo |
| Product Warranty | 2 Years |
